As part of the Schneider Electric business, Eurotherm is a leading global supplier of Industrial Automation and process control,measurement and data management solutions and services. Their innovative products and solutions are designed to bring real benefits to customers by optimising processes, operations and plant efficiency.
EMC hold a wide range of products that are rich in features and designed for easy operation and reduced engineering time. This includes market-leading control algorithms, recording and data management strategies which add value to industrial processes, improving quality, reducing waste and ensuring data is kept safe for as long as it is needed.
Decades of experience in providing world-class process control, recording and automation are supported by a continuous research and development programme to ensure that solutions meet the modern challenges faced across a wide range of industries. Customers are fully supported by a global sales and service network of highly qualified engineering personnel who understand the applications and industries
Self & adaptive tuning
The 2404/2408 is a versatile, high stability temperature or process controller, with self and adaptive tuning, in 1/4 DIN and 1/8 DIN sizes. It comes with a standard 8 segment setpoint programmer, with options for one, four or twenty programs of 16 segments each. It has a modular hardware construction which accommodates a wide range of plug-in modules.
precision control with advanced features
The innovative range of 3200 series controller offers precision control of temperature and other process variables together with a host of advanced features not normally found in this class of controller.
Advanced PID algorithms for stable temperature control
The compact, 1/32 panel size, 2132 temperature controller uses advanced PID algorithms to give stable 'straight line' temperature control. Self-tuning is included to optimize the control performance without the need for specialist knowledge or training.
Precision control of temperature and process variables
The latest range of advanced process controllers from Eurotherm provide precision control of temperature and a host of other process variables together with an abundance of advanced options making it the most adaptable product in its class.
PID control and setpoint programs
The ultimate in graphical recording combined with PID control and setpoint programs. Multi loop controllers are used to control a thermal or process machine in systems which need more than one control loop within a single system.
Multi loop controllers are capable of small machine control with advanced features and options. Flexible I/O options to control and measure a multitude of processes including temperature, carbon potential, humidity, flow, pressure, level, viscosity and additive dosing.
CONTACT Us!
High Performance Control in a Versatile, Modular System.
The Foxboro PAC System enables secure and reliable process control and information recording with complete redundancy options for maximum availability.
Part of the InFusion Enterprise Control System, the PAC System is ideally suited both for stand-alone applications and for integration into a wider ArchestrA-based control solution.
AC & DC switching applications
Complete range of control input and load output configuration for both AC and DC switching applications.
Compact solution with 6 mm/0.236 in. width, allow customers to choose the combination of relays with associated sockets from wide range of available offer.
CONTACT Us!
Panel mount relays
SSP solid state relays are panel mount relays which offer complete solid state control and switching solutions with single-phase and three-phase types.
Easy product selection with simplified product nomenclature and direct heat sinks selection available in product data sheets.
Wide choice of heat sinks with thermal resistance ratings of 2.5 °C/W to 0.2 °C/W
CONTACT Us!
Graphical recording
The ultimate in graphical recording combined with PID control and setpoint programs.
The nanodac™ recorder/controller offers the ultimate in graphical recording combined with PID control for a box of its size. The compact ¼ DIN panel mount unit offers four high accuracy universal inputs for data recording and PID control. This secure data recording device with accurate control is enhanced by a full colour, ¼ VGA display to bring a crystal clear operator interface to even the smallest of machines.
CONTACT Us!
Records up to 6 Process Variables
The 4103 is a high specification, 100mm strip chart recorder, providing continuous recording for up to 6 Process Variables. Information such as channel descriptor, alarm set point and scale information can be viewed on a high resolution VFD display. Process variables including messages can be archived to an optional removable media. These units can be programmed on site via the user interface or a configuration file can be transferred using a PCMCIA card.
Vacuum fluorescent display
The 392 is a user configurable 1, 2, 3 or 4 pen, continual trace, 100mm calibrated width circular chart instrument. Current status information is presented on a front panel mounted, high visibility, vacuum fluorescent display.
The modular construction and compact design ensure that is convenient to locate, while being easy to maintain and upgrade.
CONTACT Us NOW
The Action I/Q Series
Of signal conditioners have wide ranging field configurable inputs and outputs. These DC, RTD, T/C, potentiometer, bridge/strain gauge, AC and frequency input devices incorporate TouchCalTM technology, which simplifies calibration and allows more than 90% adjustment of zero and span.
Temperature and process measurement
The 1/32 DIN 2132i and 1/8 DIN 2108i provide you with accurate indication and alarming of temperature and process measurements. Process interlocks, including over temperature furnace limits, are implemented using relay outputs.
Accurate temperature or process measurement
Available in four standard DIN formats and complementing our range of world class PID controllers the Eurotherm range of indicators and alarm units provide accurate temperature or process measurement, clear indication with alphanumeric messaging and versatile alarming strategies.
Accurate temperature & Process measurement
The Eurotherm piccolo™ P304i Melt Pressure indicator and P304c controller offer versatile solutions with advanced features and a wide range of hardware options that make them ideal for all types of plastic processing.
PID control and recording
E+PLC100 is a cleverly designed PID controller, recorder and PLC all in a compact, single box instrument with a 3.5″ TFT colour touchscreen. Using an open industry standard (IEC 61131-3) platform and a single, integrated programming environment, it dramatically reduces engineering time while offering better process performance and easier regulatory compliance.
This exceptionally compact solution combines complete PLC functionality with the best in class PID control and recording. It offers a vivid operator interface which uses familiar touchscreen controls to ensure intuitive operation. For its size, it has an impressive selection of precision I/O and is an ideal complete solution for smaller applications.
PID & PLC control
E+PLC400 is a PID controller, recorder and PLC combined in a single, modular solution which is incredibly easy to engineer. Using an open industry standard (IEC 61131-3) platform and a single, integrated programming and visualisation environment, this innovative instrument is designed to offer flexibility to match process requirements while reducing engineering time. It is feature rich and gives an enhanced user experience which delivers operational efficiency, better process performance and easier regulatory compliance.
Global distributors in supplying engineering control components
